Yeastar TE Series E1/T1/PRI VoIP GatewayTE100 / TE200
TE VoIP E1/ T1 /J1 gateway (VoIP to E1/T1/J1, and E1/T1/J1 to VoIP) supports up to 30/60 concurrent calls. TE Series offers SMBs cost effective additions to a legacy telephone system to bring the true benefits of VoIP. Yeastar ISDN VoIP Gateways bridge the gap between traditional ISDN telephony connections such as common RJ-48c / T1 interfaces to provide dial tone to most VoIP PBX phone systems including Yeastar IP PBX.
Features
|
|
Benefits
- Software configurable E1/T1/J1 ports
- Up to 60 simultaneous VoIP to ISDN calls
- Cost-effective call routing
- Easy-to-navigate Web GUI
- Simple installation and management
- Connect existing ISDN PBX to VoIP
- Connect VoIP-only system to ISDN
- Connect multiple PABX at different sites
- Compatible with various ISDN PBX, IP-PBX
| Models | TE100 | TE200 | ||||
|
E1/T1/J1 Ports (Support PRI, E&M) |
1 | 2 | ||||
| Protocol | SIP (RFC3261) | |||||
| Transport Protocol | UDP, TCP, TLS, SRTP | |||||
| Codec | G.711 (alaw/ulaw), G.722, G.726, G.729A, GSM, ADPCM, Speex | |||||
| Echo Cancellation | ITU-T G.168 LEC Echo Cancellation, Dynamic Jitter Buffer | |||||
| DTMF Mode | RFC2833, SIP Info, In-band | |||||
| Network | DDNS, Firewall, PPPoE, Static IP, QoS, Static Route | |||||
| Network Protocol | FTP, TFTP, HTTP, HTTPS, SSH | |||||
| PRI switch types | Euro ISDN, nation, Q.SIG | |||||
| Caller ID | BELL202, ETSI (V23), NTT (V23-Japan), and DTMF-based CID | |||||
| LAN | 1 10/100Mbps | 1 10/100/1000Mbps | ||||
| WAN | 1 10/100Mbps | 1 10/100/1000Mbps | ||||
| USB | 1 | |||||
| Power Supply | AC 100-240V (12V 2A) | |||||
| Dimensions (L × W × H) (mm) | 213 x 160 x 44 | |||||
| Operation Range | 0°C to 40°C, 32°F to 104°F; | |||||
| Storage Range | -20°C to 65°C, -4°F to 149°F | |||||
| Humidity | 10-90% non-condensing | |||||
| Models | TE100 | TE200 | ||||
|
E1/T1/J1 Ports (Support PRI, E&M) |
1 | 2 | ||||
| Protocol | SIP (RFC3261) | |||||
| Transport Protocol | UDP, TCP, TLS, SRTP | |||||
| Codec | G.711 (alaw/ulaw), G.722, G.726, G.729A, GSM, ADPCM, Speex | |||||
| Echo Cancellation | ITU-T G.168 LEC Echo Cancellation, Dynamic Jitter Buffer | |||||
| DTMF Mode | RFC2833, SIP Info, In-band | |||||
| Network | DDNS, Firewall, PPPoE, Static IP, QoS, Static Route | |||||
| Network Protocol | FTP, TFTP, HTTP, HTTPS, SSH | |||||
| PRI switch types | Euro ISDN, nation, Q.SIG | |||||
| Caller ID | BELL202, ETSI (V23), NTT (V23-Japan), and DTMF-based CID | |||||
| LAN | 1 10/100Mbps | 1 10/100/1000Mbps | ||||
| WAN | 1 10/100Mbps | 1 10/100/1000Mbps | ||||
| USB | 1 | |||||
| Power Supply | AC 100-240V (12V 2A) | |||||
| Dimensions (L × W × H) (mm) | 213 x 160 x 44 | |||||
| Operation Range | 0°C to 40°C, 32°F to 104°F; | |||||
| Storage Range | -20°C to 65°C, -4°F to 149°F | |||||
| Humidity | 10-90% non-condensing | |||||
